HPE Networking Instant On Switch 20p Gigabit CL4 4p Gigabit CL6 PoE 2p 10GBT 2p SFP+ 370W 1960 | JL807A

DifferentiatorPorts: 24 x 1 G
Uplink ports: 2 x SFP+ 2 x 10 GBASE-T

Power consumptionMaximum:
100-127V: 500W
200-220V: 480W
Idle:
100-127V: 40W
200-220V: 80W

Input voltage100-127VAC / 200-240VAC

Ports24 RJ-45 autosensing
10/100/1000 BASE-T ports with 4 ports
of IEEE 802.af/at/bt CL6 PoE and 20
ports of IEEE 802.af/at CL4 PoE

(IEEE 802.3u Type 100 BASE-TX, IEEE
802.3ab Type 1000 BASE-T, IEEE 802.an
10 GBASE-T);

Duplex: 100 BASE-TX: half or full;
1000 BASE-T: full only
10 GBASE-T: full only

2 SFP+ 10 GbE ports 2 RJ-45
autosensing 100/1000/10 GBASE-T ports

Switching capacity128 Gbps

Stacking capabilities4H height

Throughput95 Mpps

Memory and processorSingle-Core ARM v7 Cortex-A9 @800 MHz; 1 GB DDR3; 512 MB NAND flash; Packet buffer size: 1.5 MB

PoE capabilityTotal 370 W PoE Power (Up to 240 W of Class 6 or 370 W of Class 4 PoE)

Operating temperature0-40°C, 0-10,000 ft

Management featuresHPE Networking Instant On Cloud; Web browser; SNMP Manager

WarrantyLimited lifetime warranty with 24X7 phone support for the first 90 days and chat support for the entire warranty duration.
Community support is available for the life of the product.

Weight4.7 kg (10.4 lb)

Dimensions35.05 x 44.25 x 4.4 cm (13.80 x 17.42 x 1.73 in)
